Home » Products » Fume Extractor » Welding Fume Extractor

Welding Fume Extractor

Welding Fume Extractor
Welding Fume Extractor
Product Code : WFE 19
Trade Information
  • Main Export Market(s)
  • Asia, Middle East
  • Main Domestic Market
  • South India
  • Certifications
  • ISO 9001:2008
Product Description

Being a quality-centric organization, we are encouraged by our clients to manufacture, export and supply Welding Fume Extractor. The offered extractor is widely used in various industries for filtering air. By making use of supreme quality components, this extractor is manufactured at our advanced production unit under the supervision of our adept professionals. Before delivering it to the clients, the offered extractor is checked thoroughly by our quality checkers on various parameters to ensure its flawlessness. We assure our clients that provided Welding Fume Extractor is deliver within committed time frame.

We offer Welding Fume Extractor with suction arm to effectively collect dust particles & fumes. It is manufactured as per the global quality standards. Extraction through suction arm ensures safety of human resources and good health, by removing the welding smoke. In addition, the Welding Fume Extractor keeps production machine and product contaminant free.


How welding fumes can affect your health?

If you breathe in gases, fumes & vapors etc. in large quantities, over the years, your health will suffer. Exposure to welding fumes produce several health effects:

  • Shortness of breath
  • Fluid in lungs (edema)
  • Inflammation of lungs (pneumonitis)
  • Loss of appetite
  • Bronchitis
  • Coughing
  • Cramps
  • Irritation of the eyes, nose & chest


Other health problems related to welding fumes:

  • Hearing loss
  • Skin diseases
  • Kidney damage
  • Heart disease
  • Gastritis / ulcers of the stomach



At Cleantek, we design & manufacture Welding Fume Extractors in various capacities. Our machines cleanse the hazardous welding fumes up-to 99%, and circulate pure air. Also, we are supplying 3D articulated swing arm, 3.5 meter length, for easy fumes capture.

Models:

  • Stationary Fume Extractor
  • Portable Fume Extractor
  • Wall-Mounted Fume Extractor
How It Works:

In welding fume extractor, unclean air is drawn by the suction motor, and move energetically through the washable stainless steel mesh filter, which hold the large dust particles. Then, the air goes through fine filter fabric, where the fine dust particles are filtered. Residual air stream passes into the strong electric field, where particulate takes an electrical charge. Then, the charged particles pass into a collector plate unit which is made of a sequence of equally spaced parallel plates. Every alternate plate is charged with similar polarity (6 Kv to 7Kv) as the particles; while attract as well as collect the contaminants, they repel. These plates hold the contaminants until they are washed away. Additional air pass into the gas stage activated carbon filter. Here activated carbon absorbs the toxic gases. Then pure air sent out through the exhaust line to the atmosphere.

Key Features:

  • Mobile Welding Fume Extractor with Electrostatic Precipitator, ideal for welding fume filtration uses.
  • Movable arm that can be set in any position of three -dimensional space; workers can perform more efficiently.
  • Easy to move & maintain.
  • Perfect for continuous, trouble-free working.
  • CE approved, energy efficient induction motor.
  • High suction airflow rate and purifying efficiency.
  • Electronic panel board for warning of Filter cleaning stage.
  • Helps maintain pollution-free atmosphere.
  • Improved productivity and reduced maintenance.
  • Easy to clean multi stage filters, spark arrester and electrostatic filter.
  • Rugged design
  • Less power consumption
  • Highly efficient
  • Low maintenance cost


Applications:

  • Welding fume filtration / welding fume destroyer system.
  • Robotic welding fume extraction.
  • Soldering pot fume filtration.
  • Laser fume filtration.
  • Dust, hazardous fume filtration.
  • Medical lab gas, dust, fume filtration.
  • Pharmaceutical lab dust filtration.





APPLICATIONS

FEATURES

Welding fume Filtration

Mobile / Stationary models available

Soldering fume Filtration

Easy moveable flexible suction Arm

Laser Fume Filtration

99.9 & % HEPA filter options

Hazardous Fume / Dust Filtration

Easy replace /Clean the filters

Medical Lab Gas / Fume / dust Filtration

3 stage filtration

Pharma lab dust filtration

Improves productivity and reduce maintenance



Parameters

Model FE 300

Model FE500

Motor Power

2.2 Kw

3.7 Kw

Airflow

1900 m3/Hr

2200 m3/Hr

Vacuum

200mm of Wg

300mm of Wg

Filtration Stage

SS Spark Arrester, Pre filter, Activated carbon filter, Electrostatic filter

SS Spark Arrester, Pre filter, Activated carbon filter, Electrostatic filter

Version

Portable model with brake wheels

Portable model with brake wheels

Suction hose diameter

150mm

150mm

Filtration efficiency

99.90%

99.90%

Insulation class

F

F

Motor Protection

IP 55

IP 55

Overall Dimensions

600x610x1300

610x610x1300

Weight

125kg

149kg
