Price 125000 आईएनआर/ Number

मूल्य/उद्धरण प्राप्त करें

MOQ : 1 Number

दक्षता
Up to 99%

स्क्रबर टाइप
Dry Type

सेंसर टाइप
Particulate Sensor

पावर सोर्स
Electric

तापमान
Up to 55°C

ओरिएंटेशन
Vertical

एयर फ्लो
3000 m³/hr

उपयोग/अनुप्रयोग
Industrial Dust Collection

ऑटोमेशन ग्रेड
Semi-Automatic

प्रॉडक्ट टाइप
Centralized Dust Collector

मटेरियल
Mild Steel (MS)

कूलिंग सिस्टम

शोर का स्तर
Below 75 dB

प्रोसेसिंग का समय
Continuous

क्षमता
3000 m³/hr

वोल्टेज
415 V

वज़न
Approx. 450 kg

आयाम (एल* डब्ल्यू* एच)
1800 x 1200 x 2300 mm

सतह
Powder Coated

Motor Power
5 HP

Mounting Type
Floor Mounted

Number of Filter Bags
4 Bags

Mobility
Fixed Installation

Static Pressure
200 mm WG

Installation Area
Indoor / Outdoor

Filter Type
Cartridge/Bag Filter

Inlet/Outlet Size
200 mm / 250 mm

Dust Removal System
Automatic Pulse Jet Cleaning

Minimum Order Quantity
1 Number

मुख्य घरेलू बाज़ार
साउथ इंडिया

We are instrumental in offering high quality range of Centralized Dust Collector. It is manufactured using high grade components and cutting edge technology under the guidance of skilled team of professionals. The offered dust collector is widely used to provide clean and hygienic environment in different industries. In addition, our quality examiner conduct a series of test on this dust collector in order to eradicate any kind of defect in it. We offer this Centralized Dust Collector in different specifications to meet the varied needs of clients at reasonable prices.

Following are the salient features of our range:

Compact size
Noiseless operation
Spark Arrester
Wet particles suction
Available in Different Power Capacities
Strong suction power
High Efficiency
Stainless steel version (Custom Made)
Wide Application range
Simple Installation

Applications:

Polishing Machines
Wood Cutting Machinery
Rubber Grinding Machines
Surface Grinding Machines
CNC Cutting Machines
Drilling Machines
Sharpening Machines
Honing Machines
CNC Router
Sand Blasting Machines
Milling Machines
Small machine Tools
CNC Routers
Sand Blasting Machines
Welding & cutting Machines

Technical Specifications:

Power (Hp)	1
Voltage (V/ Hz)	415/50
Airflow	1000
Vacuum (mm of Wg)	75
Suction inlet (mm)	100

Parameters	DC50	DC100	DC200	DC300
HP	0.5	1	2	3
Volts/Hz	230V/50Hz	415/50	415/50	415/50
Airflow in m3/Hr	500	1000	1850	2900
Speed in RPM	2880	2880	2880	2880
Suction inlet mm	50	100	100	100
Motor Protection	IP55	IP55	IP55	IP55
Weight in Kg	25	35	40	75
Insulation class	F	F	F	F
