Compact Dust Collector

Name: Compact Dust Collector
Brand: CLEANTEK

Get a Price/Quote

MOQ : 1 Piece

Compact Dust Collector Specification

Sensor Type
Integrated Differential Pressure Sensor

Power Source
Electric

Measurement
Particulate Matter Density

Automation Grade
Semi-Automatic

Air Flow
Max 5000 m3/hr

Usage & Applications
Industrial Dust Extraction and Air Filtration

Temperature
Ambient to 60C

Instruments Type
Filtration Unit

Efficiency
99%

Display Type
Analog

Orientation
Vertical

Product Type
Compact Dust Collector

Material
Mild Steel

Cooling System
Air Cooled

Noise Level
<80 dB

Processing Time
Continuous

Capacity
500 to 5000 m3/hr

Voltage
415 V

Weight
Approx. 150 kg

Dimension (L*W*H)
900 x 700 x 1600 mm

Surface
Powder Coated

Inlet/Outlet Size
150 mm / 200 mm

Mounting Type
Floor Standing

Motor Power
2 HP to 5 HP (as per model)

Cleaning Method
Manual Shaker

Fan Type
Centrifugal Fan

Filter Type
Cartridge / Bag Filter

Color
Blue and White

Dust Discharge System
Bottom Drawer Type

Number of Filters
24 (as per model)

Compact Dust Collector Trade Information

Minimum Order Quantity
1 Piece

FOB Port
chennai

Supply Ability
5 Pieces Per Week

Delivery Time
1 Week

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Export Market(s)
Asia

Main Domestic Market
South India

Certifications
ISO 9001-2015

About Compact Dust Collector

Compact Dust Collector is a single unit or an assemblage of devices, utilized for the separation of particulate substance from the process air. This air pollution control device is capable to maintain the air quality. The industries which use this highly functional device are food & agriculture, metal, chemical processing, woodworking, pharmaceutical etc. This collector can collect dirt, chemicals, dust and trash so that the air quality of workplaces can be improved. Compact Dust Collector ensures the removal of contamination from the air, providing cleaner air, which is free from dirt, dust and debris. Its optimal way of operation does not make interference with the mechanics and thus chances of broken equipment is eliminated. It does not ask for relentless attention or repairs.

Key Points:

1) Do away with all sort of risks, enabling the machines to work at optimum performance.
2) Ensures the safety of everyone inside the area.
3) Significantly reduce the cost of operation and maintenance.
4) Enhancing the air quality making the environment more breathable.

Superior Efficiency and Robust Performance

Engineered for industrial environments, this dust collector delivers up to 99% filtration efficiency, ensuring cleaner air and improved workplace safety. Its vertical, floor-standing design is space-efficient, while the centrifugal fan and integrated differential pressure sensor provide consistent airflow of up to 5000 m3/hr. The semi-automatic operation and analog display make it straightforward and reliable for daily use.

Easy Maintenance and User-Friendly Operation

Featuring a manual shaker cleaning mechanism and bottom drawer dust discharge, the unit ensures hassle-free maintenance. The powder-coated surface provides durability, while the modular structure allows for quick inspections or filter changes. The air-cooled system and low noise output further contribute to comfortable, uninterrupted operation in various industrial settings.

Versatile Applications Across Industries

Ideal for multiple industrial dust extraction scenarios, this filtration unit is suitable for factories, workshops, and processing plants handling particulate matter. Its sturdy build, continuous processing, and compatibility with ambient temperatures up to 60C make it a dependable choice for clean air and regulatory compliance across a range of sectors.

FAQs of Compact Dust Collector:

Q: How does the compact dust collector remove and collect dust from the air?

A: This dust collector draws in contaminated air using a centrifugal fan. Dust-laden air passes through cartridge or bag filters (2-4, depending on model), trapping particles while clean air is released. Dust accumulates in the bottom drawer, which can be easily emptied as needed.

Q: What is the process for cleaning the filters in this dust collector?

A: The unit uses a manual shaker cleaning method. Simply activate the shaker mechanism to dislodge dust from the filter surfacesthis keeps filtration efficiency high and extends filter lifespan. Filter maintenance is straightforward and does not require disassembly of the entire unit.

Q: When should I perform maintenance or clean the dust collectors filters?

A: Maintenance should be performed regularly, based on usage intensity and particulate levels. The integrated differential pressure sensor can help indicate when the filters need cleaning by showing a rise in pressure drop across the filters. Typically, inspections are recommended weekly in most industrial environments.

Q: Where can this dust collector be installed for best results?

A: This floor-standing model is designed for indoor installation in industrial settings such as workshops, manufacturing units, and processing facilities. It should be placed near dust-generating equipment for optimal air extraction and filtration.

Q: What types of industrial applications is this dust collector suitable for?

A: The compact dust collector is ideal for dust extraction and air filtration in industries such as metalworking, woodworking, pharmaceuticals, textiles, and more. It effectively removes particulate matter, protecting workers and equipment from airborne dust hazards.

Q: How does using this dust collector benefit my workplace?

A: Employing this filtration unit enhances workplace air quality by efficiently capturing up to 99% of dust particles. This not only safeguards employee health and well-being but also helps maintain compliance with environmental and safety regulations.
