Portable Welding Fume Extractor
Portable Welding Fume Extractor
Portable Welding Fume Extractor
Portable Welding Fume Extractor
Portable Welding Fume Extractor
Portable Welding Fume Extractor

Portable Welding Fume Extractor

MOQ : 1 Piece

Portable Welding Fume Extractor Specification

  • Sensor Type
  • Air Quality Sensor
  • Temperature
  • Max Operating Temp 60C
  • Efficiency
  • >99%
  • Usage & Applications
  • Welding, Soldering, Metal Fabrication
  • Automation Grade
  • Semi-Automatic
  • Air Flow
  • 2600 m/h
  • Display Type
  • Analog
  • Scrubber Type
  • Filter Cartridge
  • Measurement
  • Particulate Filtration
  • Instruments Type
  • Fume Extraction
  • Orientation
  • Vertical
  • Power Source
  • Electric
  • Product Type
  • Portable Welding Fume Extractor
  • Material
  • Powder Coated Steel
  • Cooling System
  • Air Cooled
  • Noise Level
  • <72 dB(A)
  • Processing Time
  • Continuous
  • Capacity
  • Up to 35 m/min
  • Voltage
  • 220V / 50Hz
  • Weight
  • 65 kg
  • Dimension (L*W*H)
  • 600 x 500 x 1000 mm
  • Surface
  • Powder Coated
  • Extraction Efficiency
  • >99.97% for 0.3 micron particles
  • Filter Type
  • HEPA and Activated Carbon
  • Number of Arms
  • Single Flexible Extraction Arm
  • Motor Power
  • 1.1 kW
  • Color
  • Blue / Grey
  • Protection
  • Overload Protection
  • Arm Length
  • 2 Meters
  • Mobility
  • Mounted on Castor Wheels
  • Maintenance
  • Easy Access for Filter Replacement
  • Control Panel
  • Integrated Switch and Speed Controller


Portable Welding Fume Extractor Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • FOB Port
  • chennai
  • Supply Ability
  • 10 Pieces Per Week
  • Delivery Time
  • 1 Week
  • Sample Policy
  • Sample costs shipping and taxes has to be paid by the buyer
  • Main Domestic Market
  • South India
  • Certifications
  • ISO 9001:2008


About Portable Welding Fume Extractor

Since inception, our fire is focused in manufacturing, exporting and supplying supreme quality Portable Welding Fume Extractor. The provided fume extractor is used to collect welding fume and dust from the source. It id manufactured by making use of top grade components and pioneering technology in the observation of our adroit professionals. Moreover, the offered Portable Welding Fume Extractor is highly appreciated for its portable model and can be availed by our esteemed clients at market-competitive prices.

Features:

  • Hassle-free functionality
  • Robust construction
  • User-friendly design
  • Optimum performance



Advanced Filtration Technology

The extractors dual filter system combines high-efficiency HEPA with activated carbon, ensuring superior removal of welding fumes and particulates. Its filter cartridge design enables effective separation, significantly improving air quality. This system is perfectly suited for applications including welding, soldering, and other metal fabrication processes where airborne contaminants pose health risks.


Flexible and Mobile Operation

Featuring a single, flexible arm with a reach of two meters, this extractor allows precise targeting of fume sources. The castor-wheeled base provides effortless mobility, making it ideal for dynamic workspaces. Its integrated control panel facilitates easy adjustment of extraction speed, while overload protection ensures safe, durable performance throughout continuous operation.


User-Friendly Maintenance & Handling

Designed for convenience, the extractor enables easy filter replacement through accessible panels. Its powder-coated steel construction ensures durability, and the air-cooled system maintains reliable motor performance. With noise levels below 72 dB(A), the unit operates unobtrusively, contributing to a safer, more productive working environment.

FAQs of Portable Welding Fume Extractor:


Q: How does the portable welding fume extractor capture hazardous particles from welding operations?

A: This extractor uses a HEPA filter combined with activated carbon to remove over 99.97% of particulates as small as 0.3 microns. The flexible extraction arm positions the intake close to the fume source, ensuring effective capture before contaminants spread.

Q: What is the process for replacing the filters, and how often should maintenance be performed?

A: Filters are accessible via easy-to-open panels, facilitating quick replacements without specialized tools. Filter replacement intervals depend on usage frequency and fume concentration; typically, maintenance is recommended every few months to sustain optimal filtration efficiency.

Q: Where can this fume extractor be used most effectively?

A: It is best suited for welding, soldering, and metal fabrication areas, especially where mobility and localized extraction are required. Its robust construction and flexibility also make it ideal for workshops, factories, and educational training facilities.

Q: When should the speed of extraction be adjusted on the integrated control panel?

A: Speed adjustment is useful for matching the extraction rate to the intensity of fume production. Higher speeds can be set during heavy-duty operations, while lower speeds suffice for lighter tasks, optimizing energy use and maintaining air quality.

Q: What benefits does the castor wheel mobility offer for users?

A: The mounted castor wheels allow users to easily relocate the unit across different workstations or confined spaces, enhancing operational flexibility and ensuring maximum coverage during varying tasks.

Q: How does the overload protection feature contribute to operational safety?

A: Overload protection automatically shuts down the motor if excessive electrical load is detected, preventing damage and reducing the risk of overheating during continuous usage. This extends equipment lifespan and safeguards personnel.

Q: Can the extractor operate continuously, and what is its maximum capacity?

A: Yes, the extractor supports continuous operation and can process up to 35 cubic meters per minute, making it reliable for extensive work sessions without compromising performance.

Tell us about your requirement
product

Price:

Quantity
Select Unit

  • 50
  • 100
  • 200
  • 250
  • 500
  • 1000+
Additional detail
Mobile number

Email

More Products in Fume Extractor Category

Portable Fume Extractor Unit
