Send InquiryCentralised Dust Extraction System
Price 25000 INR/ Unit
MOQ : 1 Unit
Centralised Dust Extraction System Specification
- Scrubber Type
- Dry / Wet Scrubber (Optional Attachment)
- Efficiency
- Up to 99.9%
- Air Flow
- Customizable up to 50,000 m3/hr
- Power Source
- Electric
- Usage & Applications
- Industrial dust collection from multiple sources, pharma, cement, food industries, etc.
- Measurement
- Particulate Concentration
- Instruments Type
- Dust Filtration Unit
- Display Type
- Analog / Digital (as per model)
- Orientation
- Vertical / Horizontal
- Sensor Type
- Particulate Matter Sensor (optional)
- Temperature
- Ambient to 80°C
- Automation Grade
- Semi Automatic / Automatic
- Product Type
- Centralised Dust Extraction System
- Material
- Mild Steel / Stainless Steel
- Cooling System
- Air Cooled
- Noise Level
- Below 80 dB
- Processing Time
- Continuous
- Capacity
- 500 m3/hr to 50,000 m3/hr
- Voltage
- 415 V / 3 Phase / 50 Hz
- Weight
- Approx. 350 - 2500 Kg
- Dimension (L*W*H)
- As per design / customized
- Surface
- Powder Coated / Painted
- Installation Type
- Indoor / Outdoor
- Ducting Material
- GI / SS / FRP (as per application)
- Cleaning Mechanism
- Pulse Jet Cleaning
- Discharge Method
- Automatic with Rotary Airlock / Manual Option
- Suction Points
- Multiple – centralized line
- Fan Type
- Centrifugal Blower
- Inlet Size
- As per requirement
- Number of Filters
- 4 to 36 (as per capacity)
- Mounting
- Skid Mounted / Foundation Mounted
- Control Panel
- PLC Based / DOL Starter Options
- Filter Type
- Bag Filter / Cartridge Filter
- Motor Power
- 7.5 kW to 110 kW (varies as per design)
Centralised Dust Extraction System Trade Information
- Minimum Order Quantity
- 1 Unit
- Supply Ability
- 100 Units Per Day
- Delivery Time
- 1 Week
- Main Export Market(s)
- Asia, Middle East
- Main Domestic Market
- South India
- Certifications
- ISO 9001:2008
About Centralised Dust Extraction System
Owing to our huge experience and expertise in this domain, we are engrossed in manufacturing, exporting and supplying the excellent quality Centralised Dust Extraction System. The offered system is manufactured by employing utmost technical skills using premium quality components in conformity with set industrial parameters. The Provided system is highly demanded in the domestic as well as international market for its flawless collection of dust and other harmful particles and used in various industries. Moreover, our valued clients can avail this Centralised Dust Extraction System from us at rock-bottom prices.
Features
-
Low power consumption
-
Easy to install
-
Minimum maintenance
-
Power efficient
Efficient Industrial Dust Control
Engineered for industries that demand high air quality, the Centralised Dust Extraction System utilizes advanced filtration technology. With customizable suction points, pulse jet filter cleaning, and low-noise centrifugal blowers, it ensures continuous dust removal and safe workspaces, significantly reducing airborne contaminants throughout large manufacturing environments.
Customizable to Your Operations
This dust extraction solution adapts to specific industrial requirements, offering options for bag or cartridge filters, flexible ducting materials, and both foundation or skid mounting. The system efficiently manages dust from multiple sources across production lines, with PLC-based automation and adjustable capacity, making it an ideal choice for a variety of processing applications.
Easy Maintenance and Reliable Performance
Built for durability, the system offers automatic cleaning, rotary airlock discharge, and robust construction in mild or stainless steel. It is suitable for ambient to slightly elevated temperatures and delivers dependable results with minimal downtime, optimizing both operational efficiency and worker safety.
FAQs of Centralised Dust Extraction System:
Q: How does the Centralised Dust Extraction System work?
A: This system employs a centrifugal blower that draws dust-laden air from multiple points into filters (bag or cartridge type). The pulse jet mechanism cleans the filters, ensuring efficient and uninterrupted dust removal. Collected dust is discharged via a manual or automatic rotary airlock, maintaining continuous operation.Q: What types of filters are available and how are they selected?
A: The system can be fitted with either bag filters or cartridge filters, chosen based on the nature of the dust, required efficiency, and industrial application. The number of filters (4 to 36) is selected as per air flow requirements and particulate load.Q: When should I use the automatic discharge with rotary airlock over the manual discharge option?
A: Automatic rotary airlock discharge is ideal for large-scale or continuous operations, reducing manual intervention and the risk of exposure to collected dust. Manual discharge may be chosen for smaller installations or where periodic cleaning is feasible.Q: Where can the dust extraction system be installed?
A: It is designed for both indoor and outdoor installations, with mounting options that include skid and foundation mounting. Ducting can be customized in GI, SS, or FRP based on environmental and process requirements.Q: What is the process for integrating this system into my existing production line?
A: Integration starts with assessing your facilitys dust sources and required air flow. The system is then configured for suction points, duct layout, filter type, and discharge method. Installation is completed on-site, with electricals connected to the PLC/DOL starter, ready for commissioning and operation.Q: How does the Centralised Dust Extraction System benefit my facility?
A: It ensures workplace air quality compliance, minimizes cleaning and maintenance burdens, improves worker health, and supports safe, efficient continuous operations with up to 99.9% dust collection efficiency.Q: What industries typically use this dust extraction system?
A: Common applications include the pharmaceutical, cement, food, and other process industries that generate significant particulate matter and require centralized, reliable dust management.
