Send InquiryIndustrial Centralized Dust Collection System
MOQ : 1 Piece
Industrial Centralized Dust Collection System Specification
- Power Source
- Electric
- Automation Grade
- Fully Automatic
- Measurement
- Monitoring of Differential Pressure, Air Flow & Filter Health
- Display Type
- Digital/Analog
- Temperature
- Up to 80C
- Orientation
- Vertical
- Scrubber Type
- Dry Dust Collector
- Sensor Type
- Pressure and Air Flow Sensors
- Air Flow
- Adjustable
- Usage & Applications
- Central dust extraction in multiple industrial applications such as grinding, polishing, sanding, powder handling, and food processing.
- Efficiency
- >99%
- Instruments Type
- Electrical Control Panel
- Product Type
- Industrial Centralized Dust Collection System
- Material
- Mild Steel
- Cooling System
- Air Cooled
- Noise Level
- Below 72 dB
- Reactor Thickness
- 6 mm
- Processing Time
- Continuous Operation
- Capacity
- 1500-100000 CFM
- Voltage
- 415 V AC, 3 Phase, 50 Hz
- Weight
- Varies as per model (Starting from 900 kg)
- Dimension (L*W*H)
- Customized as per requirement
- Surface
- PPG Coated/ Powder Coated
- Safety Feature
- Overload Protection, Emergency Stop
- Duct Material
- Galvanized Iron / Stainless Steel (optional)
- Number of Filter Bags
- Configurable up to 120
- Motor Power
- 7.5 kW - 55 kW as per model
- Filter Type
- Bag Filter/Cartridge Filter (Modular)
- Dust Discharge Method
- Dust Bin / Rotary Airlock Valve
- Control System
- PLC With HMI
- Suction Points
- Multiple, custom designed as per application
- Color
- Industrial Grey / Customized
- Cleaning Mechanism
- Automatic Online Pulse Jet Cleaning
- Mobility
- Fixed
- Installation Type
- Floor Mounted
- Working Pressure
- -1500 mm WG to -200 mm WG
- Compressed Air Required
- 5-6 Bar
Industrial Centralized Dust Collection System Trade Information
- Minimum Order Quantity
- 1 Piece
- FOB Port
- chennai
- Supply Ability
- 10 Pieces Per Day
- Delivery Time
- 1 Week
- Sample Policy
- Sample costs shipping and taxes has to be paid by the buyer
- Main Export Market(s)
- Africa, Asia
- Main Domestic Market
- South India
- Certifications
- ISO 9001:2015
About Industrial Centralized Dust Collection System
Capitalizing on modern and advance technological improvement, our company is able to establish ourselves as a reputed entity which is engrossed in manufacturing, exporting and supplying highly efficient Industrial Centralized Dust Collection System. The offered dust collection system is installed in a number of industries like food, chemical, pharmaceutical and many others due to its high efficiently and quick dust collection. The provided dust collection system is manufactured by making use of high quality components and latest technologies. Additionally, the offered Industrial Centralized Dust Collection System can be availed by our respected clients at marginal prices.
Features ofIndustrial Centralized Dust Collection System.:
- Sturdy constructed
- Easy installation
- Low noise generation
- Minimum maintenance
Advanced Modular Design for Versatile Applications
Our dust collection system is engineered for flexibility, offering modular installation with configurable filter bags and suction points for any industrial setup. Whether for grinding, polishing, or powder handling, the system adapts seamlessly to diverse operational requirements, ensuring optimal dust extraction where needed.
Automated Cleaning and Smart Control
Equipped with an automatic online pulse jet cleaning mechanism and PLC with HMI, the system ensures consistent filter performance and low maintenance downtime. Real-time monitoring via pressure and air flow sensors allows operators to track filter health and overall system status effectively, facilitating predictive maintenance.
Safety and Efficiency at the Core
Safety is prioritized with integrated overload protection and emergency stop features. Highly efficient (over 99%) filtration is achieved, maintaining air quality and worker safety. The system operates quietly and continuously, with customizable air flow to match process demand, making it ideal for high-performance industrial environments.
FAQs of Industrial Centralized Dust Collection System:
Q: How does the automatic pulse jet cleaning mechanism work in the dust collection system?
A: The automatic online pulse jet cleaning system uses controlled bursts of compressed air to dislodge dust from the filter bags or cartridges while the system is operating. This process maintains consistent filtration efficiency and extends filter life without interrupting dust extraction activities.Q: What are the benefits of using a centralized dust collection system in industrial settings?
A: A centralized dust collection system improves workplace air quality, enhances equipment life, and supports regulatory compliance. Its efficient dust extraction minimizes manual cleaning, reduces health risks, and keeps operational areas free of airborne contaminants.Q: When should the filter bags or cartridges be replaced or maintained?
A: Filter maintenance is guided by real-time monitoring of differential pressure and air flow. When sensors indicate sustained abnormal readings or reduced filter health, scheduled maintenance or replacement should be performed to preserve high filtration efficiency.Q: Where can this dust collection system be installed within an industrial plant?
A: The system is typically floor-mounted and designed to integrate with multiple suction points across production zones. It can be customized to fit specific spatial requirements and process layouts, utilizing galvanized iron or stainless steel ductwork as needed.Q: What process is followed for dust discharge and management in this system?
A: Collected dust is discharged via a dust bin or rotary airlock valve, depending on installation preferences. These options allow for safe, controlled removal and handling of dust, supporting uninterrupted, continuous operation.Q: How is the system controlled and monitored for performance and safety?
A: A PLC with HMI provides user-friendly control and monitoring interfaces, tracking differential pressure, air flow, and filter health. Safety features such as overload protection and emergency stop protocols ensure secure operation even during unexpected events.Q: What usage and application scenarios are suitable for this dust collector?
A: Ideal for centralized dust extraction in grinding, polishing, sanding, powder processing, and food production environments, the systems modular and customizable design allows it to meet the needs of various industries with demanding air quality standards.
